| Place of Origin: | Beijing, China |
|---|---|
| Brand Name: | ivan |
| Model Number: | AF410F |
| Minimum Order Quantity: | 10 pieces |
| Price: | $95.00/pieces 10-99 pieces |
| Packaging Details: | carton |
| Supply Ability: | 3000 Piece/Pieces per Month |
| Warranty: | 12 Months | Type: | Current Sensor |
|---|---|---|---|
| Customized Support: | OEM, ODM | Product Name: | Wind Vane Anemometer |
| Power Supply: | 12-24VDC | Measuring Range: | 0-70m/s |
| Output: | 0-10V/4-20mA | Material: | ABS |
| Application: | HVAC Test | Port: | Tianjin |
Specifications | |
Power Supply | 12V DC/AC 24V DC/AC 5VDC/AC {Customization} |
Measure Range | 0-5m/s 0-10m/s 0-15m/s 0-20m/s 0-30m/s |
Output | 0-5V 0-10V 0-20mA 4-20mA Rs485{modbus-RTU} |
Measure Accuracy | ±{0.2m/s +3%of MV} |
Consumption | 2.5W |
Protection Rating | IP65 |
Response Latency | 0.2 s |
Resolution | 0.01m/s |
Sensing Elements | Thermal film sensor |
Working Environment | Temperature: -20-85ºC Humidity:5%-95% |
Probe Length | Installation of flange :150mm / Customization |
Material of Probe | ABS Engineering plastic |
